PT-15-12
| 型号 | P-15 | P-12 |
|---|---|---|
| 单元构造(Drivers) | HF:1×3"/LF:1×15" | HF:1×1.75"/LF:1×12" |
| 频率响应(Frequency response) | 55Hz-20KHz | 50Hz-20KHz |
| 扩散角度(Coverage Angle) | 90°H× 50°V | 90°H× 70°V |
| 灵敏度(Sensitivity) | 100dB | 97dB |
| 声压级(Output SPL) | 128dB | 126dB |
| 额定功率(Rated power) | 600W | 500W |
| 峰值功率(Peak power) | 1800W | 1500W |
| 额定阻抗(Rated impedance) | 8Ω | 8Ω |
| 箱体尺寸(宽×深×高)(Box Size)（W×D×H） | W470mm×D500mm×H700mm | W361mm×D398mm×H615mm |
| 重量(Weight) | 25KG | 22KG |
